DAHUA 2MP IPC-HDW2249T-S-PRO

The DH-IPC-HFW2249M-S-B-PRO is a 2 MP Eyeball-style network camera from Dahua’s WizSense PRO line. It offers WizColor technology for color imaging in low light, a built-in warm LED light (up to 50 m), AI-based perimeter protection (intrusion and tripwire with human/vehicle classification), and supports smart video compression to save bandwidth and storage.

• Intelligence / AI Features

  • IVS / Perimeter Protection: Supports intrusion and tripwire rules that classify and detect both human and vehicle targets.

  • SMD Plus: More accurate motion detection by filtering out non-relevant movement.

  • Smart Search: When used with a compatible Dahua NVR, you can search for events like intrusion or tripwire via refined AI-based event extraction.

  ---

  Video / Imaging

  • Encodings: H.265, H.264, H.264H, H.264B, MJPEG (sub stream)

  • Frame Rate: 1080p @ 25/30 fps (main stream)

  • Streams: 2 streams (Main + Sub)

  • ROI (Region of Interest): Yes (4 regions)

  • Image Rotation: 0° / 90° / 180° / 270° supported

  • Privacy Masking: Up to 4 zones

  ---

  Network & Storage

  • Network Port: RJ-45 (10/100 Mbps)

  • Protocols Supported: IPv4, IPv6, HTTP, TCP, UDP, RTSP, SMTP, FTP, DDNS, NTP, IGMP, ONVIF S/G/T, etc.

  • Storage Options: Micro SD card (max 256 GB), FTP, NAS

  ---

  Power & Environment

  • Power Supply: 12 V DC or PoE (802.3af)

  • Power Consumption:

    • Typical: ~1.5W (12 V DC), ~1.9W (PoE)

    • Max (with warm light + intelligence): ~5.3 W (12 V) / ~6.3 W (PoE)

  • Operating Temperature: –40 °C to +60 °C

  • Humidity: ≤ 95% (non-condensing)

  • Weather Protection: IP67 rated

  ---

  Physical

  • Body: Metal + Plastic

  • Dimensions: 201.0 × 103.8 × 97.8 mm

  • Weight: ~0.66 kg (1.46 lb)
